20 Common Protocols and Their Well-Known Port Numbers

The port number is a numeric identifier used to route packets to the correct application on a computer.

Just as Media Access Control (MAC) addresses are used to deliver frames to the correct physical computer or you can say to the network adapter.

And IP Addresses are used to route packets to the correct logical computer (x.x.x.x) , Port numbers are used to route a packet to the correct application after the packet has arrived at its destination computer.

We know that on a single computer/Server their are lots of applications are running.When a packet arrives at that server, it cannot be delivered to ust any application.For example, HTTP client requests are not going to be understood by an LDAP server application.

Port numbers range from 1 to 65,000.Most established Internet protocols have assigned port numbers,reffered to as well-known port numbers.

By this it is easy for firewall to allow or block request on particular port.

For example,if a firewall were configured to block port 80,HTTP clients would not be able to pass through the firewall and communicate with any internal virtual servers.You will have to open specific ports in order to let the proper traffic pass.

For an extra measure of security, you can usually change the port numbers that an application uses.For example,you might change your POP3 virtual server and all POP3 clients too use port 28,345 instead of the default 110.

The drawback of doing this is that you will have to manually chang any application that will need to communicate with the server.



Powershell – How To – SID To User

Step 1: Domain User to SID

This will give you a Domain User’s SID
$objUser = New-Object System.Security.Principal.NTAccount(“DOMAIN_NAME”, “USER_NAME”)
$strSID = $objUser.Translate([System.Security.Principal.SecurityIdentifier])

Step 2: SID to Domain User

This will allow you to enter a SID and find the Domain User
$objSID = New-Object System.Security.Principal.SecurityIdentifier `
$objUser = $objSID.Translate( [System.Security.Principal.NTAccount])


$objUser = New-Object System.Security.Principal.NTAccount(“LOCAL_USER_NAME”)
$strSID = $objUser.Translate([System.Security.Principal.SecurityIdentifier])

Found on Spiceworks:

Dlightdily : “ Have you any query ? , Post It below in comment box” !

windows script to check Server Uptime


Ever wanted a simple HTML report showing you the UP/DOWN status of your servers?

And for a little extra flavor how long that server has been up for?

Some basic disk information?

1. Download the script to your favorite location and name it Uptime.ps1

2. Open a Powershell prompt and type: Get-Help pathtoscript\Uptime.ps1 –Full

3. Edit PARAM section so that variables match your environment.

4. Edit $Key variable with random numbers, this is your encryption key.

5. Run it manually once, if you are using alternative credentials script will prompt you for password and save those credentials to a file.

To run as a scheduled task:

1. Create the scheduled task and set your trigger (hourly?)
2. For action the Executable should be Powershell.exe
3. For Arguments use: -ExecutionPolicy Bypass -File pathtoscript\Uptime.ps1


Source Code

This script has not been checked by Dlightdaily. Please understand the risks before using it.


     Simple HTML report generator for UP/DOWN status of servers.
     Create a simple UP/DOWN report, with length of uptime report in a simple HTML
     report.  Also includes a “lowest” disk alert, showing you whichever disk has the
     lowest amount of disk space and how much that is (bar graph).  There is also
     a detailed disk report you can click on to view.
     Will accept an secondary credential and use that to gather information.  The
     username and password are stored in an encrypted file in the path you designate.
     Since this script is intended to be run from a scheduled task, it is important
     to modify the PARAM section to suit your needs.
     How to Run:
     Make sure to run the script once on the server you intend to run the scheduled
     task.  The script will prompt for the specified credential password on the first
     run (or any time you change the credential username).  After that first run it
     will run without prompting.
     *** IMPORTANT ***
     Required:  Modify the $Key variable (line 74) to get unique encryption on your
     Will accept a comma seperated array of server names and if not specified default
     to load the server names from a text file.  Make sure to edit the Param section
     to fit your environment.  Will also accept object input from Get-ADComputer.
.PARAMETER AlertThreshold
     A number representing the % that free space has to go below to trigger an alert
     (changing the display to red).
     The output path and file name for the HTML report.  Make sure to edit the Param
     section to fit your environment.
.PARAMETER Credential
     Specify the alternative credential
     Path where the script will store the encrypted password file.
     Produces the report based on the servers in C:\utils\servers.txt and will save the
     report at c:\utils\uptime.html
     .\Uptime.ps1 -Servers server1,server2,server3 -path \\webserver\share\uptimereport.html
     Will create the uptime report for servers 1,2 and 3 and save the report at
     .\Uptime.ps1 -Servers server1,server2,server3 -AlertThreshold 25
     Will create the uptime report for servers 1,2 and 3 and if the lowest disk free percentage
     is below 25% it will show up in red.
     Author:        Martin Pugh
     Twitter:       @TheSurlyAdm1n
     Spiceworks:    Martin9700
         1.7        Added the ability to use alternative credentials.  Added quite a bit of error
                    handling and verbose output (if wanted).  Added the ability for the script to
                    accept pipeline input from Get-ADComputer as well as other pipeline items.
         1.6        Added remaining disk information in a more detailed report below the primary
                    status table.  Click on the “Show Disk Detail Report” link to display the detailed
         1.5        Added the “Lowest Disk Status” column.  The script will now look at all disk
                    volumes and report on the one with the lowest free disk space.  It will so the free
                    space as a percentage of the total.  By default if that percentage drops below 10%
                    it will “alert” and show that percentage in red.  This setting is configurable
                    using the -AlertThreshold parameter.
         1.0        Initial release
Param (
     [string[]]$Name = (Get-Content “c:\utils\servers.txt”),
     [int]$AlertThreshold = 10,
     [string]$Path = “c:\utils\uptime.html”,
     [string]$Credential = “surly\administrator”,
     [string]$PathToCred = “c:\utils”

Begin {
     Function Get-Credentials {
         Param (
             [String]$AuthUser = $env:USERNAME
         $Key = [byte]29,36,18,74,72,75,85,52,73,44,0,21,98,76,99,28
         #Build the path to the credential file
         $CredFile = $AuthUser.Replace(“\”,”~”)
         $File = $PathToCred + “\Credentials-$CredFile.crd”
         #And find out if it’s there, if not create it
         If (-not (Test-Path $File))
         {    (Get-Credential $AuthUser).Password | ConvertFrom-SecureString -Key $Key | Set-Content $File
         #Load the credential file
         $Password = Get-Content $File | ConvertTo-SecureString -Key $Key
         $AuthUser = (Split-Path $File -Leaf).Substring(12).Replace(“~”,”\”)
         $AuthUser = $AuthUser.Substring(0,$AuthUser.Length – 4)
         $Credential = New-Object System.Management.Automation.PsCredential($AuthUser,$Password)
         Return $Credential

    Write-Verbose “$(Get-Date): Script begins!”

    #Define static HTML
     $HeaderHTML = @”
<style type=’text/css’>
body { background-color:#DCDCDC;
table { border:1px solid gray;
   font:normal 12px verdana, arial, helvetica, sans-serif;
   border-collapse: collapse;
th { color:black;
   border: 1px solid black;
   font:normal 16px verdana, arial, helvetica, sans-serif;
   background-color: #6495ED;
td.up { background-color:#32CD32;
   border: 1px solid black;
td.down { background-color:#B22222;
   border: 1px solid black;
td { border: 1px solid black;
} { background-color:#B22222;
} { background-color:#32CD32;
} { background-color:#7FFF00;
a.detail { cursor:pointer;
<script type=’text/javascript’>
     document.getElementById(“ShowHideLink”).innerHTML=”<h6>Show Disk Detail Report</h6>”
function ShowHide() {
     if (document.getElementById(“diskdetail”).style.visibility==”visible”)
         document.getElementById(“ShowHideLink”).innerHTML=”<h6>Show Disk Detail Report</h6>”
         document.getElementById(“ShowHideLink”).innerHTML=”<h6>Hide Disk Detail Report</h6>”
<h1>Server Uptime Status Report</h1>
<table class=”Main”>
<tr><th style=”width:175px;”>Server Name</th><th style=”width:125px;”>Status</th><th style=”width:475px;”>Lowest Disk Status</th></tr>


    $DiskDetailHeaderHTML = @”
<a id=”ShowHideLink” class=”detail” onClick=”ShowHide()”></a>
<div id=”diskdetail”>
<h1>Disk Detail Report</h1><p>


    $FooterHTML = @”

    $AllComputers = @()

Process {
     #Gather all computer names before processing
     ForEach ($Computer in $Name)
     {   $AllComputers += $Computer

End {
     #Sort the servers by name, then start getting information
     Write-Verbose “Sort server names and gather Credential information”
     $Name = $Name | Sort
     $DiskData = @()

    If ($Credential)
     {   $Cred = Get-Credentials $Credential

    ForEach ($Computer in $AllComputers)
     {    Write-Verbose “Testing $Computer…”
         $ErrorReport = $null
         If (Test-Connection $Computer -Quiet)
         {    #Set parameters for splat, determine if checking local
             $CredParameter = @{
                 ComputerName = $Computer
                 ErrorAction = “Stop”
             If ($Computer.ToUpper() -notlike “*$($env:COMPUTERNAME.ToUpper())*” -and $Cred)
             {   $CredParameter.Add(“Credential”,$Cred)
             #Get uptime information
             Try {
                 $WMI = Get-WmiObject Win32_OperatingSystem @CredParameter
                 If ($WMI)
                 {    $Uptime = New-TimeSpan -Start $($WMI.ConvertToDateTime($WMI.LastBootUpTime)) -End (Get-Date)
                     $UpText = “<td class=””up””>$($Uptime.Days)d, $($Uptime.Hours)h, $($Uptime.Minutes)m</td>”
                 {    $UpText = “<td class=””up””>Up</td>”
                 #Get disk information and pretty up the data
                 $Disks = Get-WmiObject Win32_LogicalDisk -Filter “DriveType=3” @CredParameter | Select `
                     @{LABEL=”Size”;EXPRESSION={[int](“{0:N0}” -f ($_.Size/1gb))}},
                     @{LABEL=”FreeSize”;EXPRESSION={[int](“{0:N0}” -f ($_.FreeSpace/1gb))}},
                     @{LABEL=”perUsed”;EXPRESSION={[int](“{0:N0}” -f ((($_.Size – $_.FreeSpace)/$_.Size)*100))}},
                     @{LABEL=”perFree”;EXPRESSION={[int](“{0:N0}” -f (100-(($_.Size – $_.FreeSpace)/$_.Size)*100))}},
                 $DiskData += $Disks
             Catch {
                 Write-Verbose “Error encountered gathering information for $Computer”
                 $ErrorReport = $Error[0]
                 $Error.Clear | Out-Null
             #Create the simple Status table
             If ($ErrorReport)
             {   $UpText = “<td class=””down””>WMI Error</td>”
                 $DiskHTML = “<div class=””red””>$($Error[0])</div>”
             ElseIf ($Disks)
             {    $LowDisk = $Disks | Sort FreeSize | Select -First 1
                 If ($LowDisk.perFree -le $AlertThreshold)
                    {    $FreeClass = “red”
                 {    $FreeClass = “free”
                 $DiskHTML = “<div class=””green”” style=””width:$($LowDisk.perUsed)%””>$($LowDisk.DriveLetter) $($LowDisk.Size)gb ($($LowDisk.perUsed)% used)</div><div class=””$FreeClass”” style=””width:$($LowDisk.perFree)%””>$($LowDisk.FreeSize)gb free ($($LowDisk.perFree)%)</div>`n”
             {    $DiskHTML = “”
             $DetailHTML += “<tr><td>$Computer</td>$UpText<td>$DiskHTML</td></tr>`n”
         {    $DetailHTML += “<tr><td>$Computer</td><td class=””down””>DOWN</td><td class=””down””></td></tr>`n”

    #Disk Details Report
     Write-Verbose “WMI data gathered, making the report”
     $Servers = $DiskData | Select Server -Unique
     ForEach ($Server in $Servers)
     {    $Server = $Server.Server
         $DiskDetailHTML += “<h3>$Server</h3>”
         $DiskDetailHTML += “<table>”
         $DiskDetailHTML += “<tr><th>Drive Letter</th><th>Volume Name</th><th>Total Disk Space</th><th>Used</th><th>Free</th><th style=””width:350px;””>Usage</th></tr>`n”
         $Disks = $DiskData | Where { $_.Server -eq $Server } | Sort DriveLetter
         ForEach ($Disk in $Disks)
         {    $DiskDetailHTML += “<tr><td>$($Disk.DriveLetter)</td><td>$($Disk.VolumeName)</td><td>$($Disk.Size)gb</td><td>$($Disk.Size – $Disk.FreeSize)gb</td><td>$($Disk.FreeSize)gb</td>”
             If ($Disk.perFree -le $AlertThreshold)
             {    $FreeClass = “red”
             {    $FreeClass = “free”
             $DiskDetailHTML += “<td><div class=””green”” style=””width:$($Disk.perUsed)%””> </div><div class=””$FreeClass”” style=””width:$($Disk.perFree)%””>$($Disk.perFree)%</div></td></tr>`n”
         $DiskDetailHTML += “</table><br>`n”

    #Combine all the HTML fragments and save to a file
     $HTML = $HeaderHTML + $DetailHTML + $DiskDetailHeaderHTML + $DiskDetailHTML + $FooterHTML
     $HTML | Out-File $Path

    Write-Verbose “$(Get-Date): Script completed!”


Found on Spiceworks:

Nagios Automation


Let’s learn about automated nagios,which is pre-build ready with nagios,frontend and database installed monitoring for you…

What is “Fully Automated Nagios”?

Fully Automated Nagios (FAN) is a Linux distribution based on CentOS that comes pre-built with some of the most commonly used tools with Nagios. FAN comprises of a CentOS Linux distribution, Nagios Core, Centreon and Nagvis. All these tools are available in a pre-built iso image that can be downloaded from the official FAN website. FAN makes the configuration of Nagios very simple by using the Centreon Graphical User Interface

What is Nagios?

Nagios is a free open-source Monitoring System that can be used to monitor your Network and Server infrastructure. Nagios gives System Administrators the ability to notify support teams with service alerts automatically. System parameters such as CPU, Load, Memory, Processes, Disk Usage and System Logs can all be monitored. Nagios can monitor local hosts and remote hosts. Nagios can be used to monitor various platforms such as Linux, Unix and Microsoft’s Windows.

What is Centreon?

Centreon is a piece of software that provides a feature rich dashboard that allows administrators to easily configure software such as Nagios. Centreon provides a dashboard where you can add hosts, select system parameters to be monitored, create alerts and produce graphs with ease. No more manual configuration of files is necessary. In this example, we are using Centreon to configure our Nagios monitoring solution.

What is Nagvis?

Nagvis is a visualization add-on for Nagios. Nagvis can be used to display a visual representation (icons, maps, pictures) of your Nagios data, thus allowing you to display a quick overview of your servers, data centres or computer rooms.

Download FAN (Fully Automated Nagios)

Download Fully Automated Nagios
From the above link, you must choose either a 32-bit or 64-bit version of the software. Once you have downloaded this software, you can either use the iso image directly to install into a virtualized environment such as VirtualBox or VMWare or you can choose to burn the iso image to a CD/DVD and then install directly onto a physical server or PC.

System Requirements

System requirements are dependant on whether you choose to use a standalone server installation or use a distributed server installation.
Minimum system requirements:
4 GB free disk space
1 GB of RAM.
1 processor core
Recommended system requirements
20 GB plus the required disk space recommended essentially for /var. Disk space needed by mysql and rrd files
2 processors core or hyper-thread for each virtualized CPU.
2 GB of RAM.

FAN Installation Guide

To install FAN, simply follow the steps below. In this example, I am using a 64-bit version and I am using Oracle’s VirtualBox software.

Installing Fully Automated Nagios

To start the installation process, place your iso image in the target systems optical drive or make your iso image available to your Virtualization software. If you are booting from a CD/DVD, you may need to alter the BIOS boot order. You will need to set this to boot from CD/DVD first. This is normally done by pressing the specified function key at system start-up.
In the example that follows I have opted for a Standalone Server Installation.

FAN – Fully Automated Nagios

At this initial screen you can choose which components you wish to install. Simply enter you choice as specified. In this example I am installing the standalone version.
FAN Initial Boot Screen

Choose Installation Language

From this next screen you need to select you language that you wish to use for this installation. In the example, I have selected “English”. Once you have made your selection, click “OK” to continue with the installation.
FAN - Select Installation Language

Choose Keyboard Type

At this screen simply choose your keyboard type. In this example, “UK” has been chosen. Once you have made your selection, click “OK” to continue with the installation.
FAN - Select Keyboard Type

Warning Message

At the following screen simply click “YES” to initialize your hard drives. Depending on your installation type (Physical/Virtual), you may not see this warning.
FAN - Initialize Disk Message

Select Partitioning Options

At this screen you need to select a partitioning option. Several are available to choose from:
Default: Use free space on selected drives and use default layout
remove all partitions on selected drives and create default layout
remove all linux partitions on selected drives and create default layout
create custom layout
In this example I have chosen the “Default” option. From this screen, you may also choose to create a custom disk partition layout. You can also view the “Release Notes”. Once you have made your selection, click “Next” to continue with the installation.
FAN - Default Partitioning Layout

Choose your Geo-Graphic Location

At this screen you need to select your location. This can be done by either clicking on the Map or selecting your time zone from the pull down menu. Once you have made your selection, click “Next” to continue.
FAN - select your location

Root Password

From this screen you need to supply a “root” password to be used for administering this system. Once you have entered your password, click “Next” to continue.
FAN - Enter root password

Installation in Progress……

Your FAN installation is now taking place. A slide show will now display some of the included monitoring software included within this installation image. Progress of the installation is indicated by the progress bar at the bottom of the screen.
FAN - Installation in Progress

Installation Complete

Congratulations, your installation is now complete. You will need to remove any media from your drives before rebooting your system.
FAN - Installation Complete, Please reboot system

Configuring your Network Interface

Once your system has rebooted, an interactive menu is displayed where you can configure your network. To configure the network, simply choose the “Network Configuration” option and click on “Run Tool”. Here you will be able to supply your network information such as IP address, Gateway and Subnet mask. If you don’t make a selection within a 30 second period, the screen will close and you will be taken to a command line. If you still need to configure your network settings, simply run the following command:
You will now be displayed a network configuration menu.
FAN - Network Configuration

Edit Devices

From this menu, select your network interface and press “Enter”.
FAN - Edit Devices

Network Interface Parameters

From this menu you can choose to either use a “DHCP” configuration or manually configure a static IP address. In the example, a “DHCP” configuration has been selected.
Once you have made your selections, click “OK”. Now select “Edit DNS Configuration”.
FAN - Network Interface Parameters

Configuring DNS and Hostname Parameters

From this menu you can supply a hostname for your system and specify which DNS servers to use for name resolution. Now click on “OK”. You will now be taken to a command line where you can login with your “root” account”. Once you have logged in, I normally carry out a reboot of the system to make sure the hostname is picked up and the IP address is also picked up.
To reboot from the command line, simply issue the following reboot command: shutdown -r now
FAN - Network Interface Parameters

Login Screen

If all has gone well, you should now see a screen similar to the one below. Now you can login with your root password.
FAN - Root Login Screen

Determine IP Address

If you are using DHCP, you will need to find your IP address that has been allocated. To do this you can issue the command:
ip a s
This command will display your IP address, you may also have used the “ifconfig” command.
In this example, we have been given the IP address of ““. It is this IP address that we need to enter into a web browser.
FAN - Display IP address command

Display FAN – Home page

Once you have identified your IP address, this can now be entered into a web browser of your choice. In the example, I am using Mozilla Firefox, however, you can use any modern browser to access your configuration screens.
FAN - Display IP address command
Now we can look at configuring some basic monitoring using Centreon in next article.

Dlightdaily : “ Post your valuable comments below to know more for nagios / fully automated nagios “ !

Offline Squid Proxy log analysis

Squid Access Log analysis with simple python command

What is SquidMagic Master?

squidmagic is a tool which is designed to analyze a web-based network traffic to detect central command and control (C&C) servers and Malicious site, using Squid proxy server and Spamhaus.


Who is  Spamhaus?

The Spamhaus Project is an international nonprofit organization that tracks spam and related cyber threats such as phishing, malware and botnets, provides realtime actionable and highly accurate threat intelligence to the Internet’s major networks, corporations and security vendors, and works with law enforcement agencies to identify and pursue spam and malware sources worldwid




You Could get many post regarding squid log analyse in a sort way which are not in depth, However, while you are doing in practice scenario, i’m sure you would get many error to run a tool.


Linux Machine (I’m Using Ubuntu 16.04)
Squidmagic Master tool
Dependent packages:


sh, termcolor, configparser, pyzmq.

So here is the step by step configuration.

Install Python 3.6 from PPA

You can also install Python 3.6 from J Fernyhough’s Personal Package Archive
Install the following requirements.
apt-get install software-properties-common python-software-properties
Run the Following command to add the ubuntu repository.
sudo add-apt-repository ppa:jonathonf/python-3.6
Update the repository
sudo apt-get update
Install Python version 3.6 on Ubuntu 16.04
and finally install Python version 3.6
sudo apt-get install python3.6
However, it can shows you the older python version which is 3.5
# python3 -V
Python 3.5.2
On my Ubuntu machine, there are two versions of python available, python3.5 as default python version and python3.6. In this step, we will change the default python version to python 3.6
sudo update-alternatives --install /usr/bin/python3 python3 /usr/bin/python3.5 1
sudo update-alternatives --install /usr/bin/python3 python3 /usr/bin/python3.6 2
sudo update-alternatives --config python3
Selection    Path                Priority   Status
* 0            /usr/bin/python3.6   2         auto mode
  1            /usr/bin/python3.5   1         manual mode
  2            /usr/bin/python3.6   2         manual mode
After the installation of python and selected a best version, we need to install python module so here is the following command to get install.
Python Packages name : python-zmq
sudo apt-get install python-zmq
Install Python Packages: sh
sh is a full-fledged subprocess replacement for Python 2.6 – 3.6, PyPy and PyPy3 that allows you to call any program as if it were a function:
pip install sh
Install Python Package : python-pip
Pip is a package management system used to install and manage software packages written in Python which can be found in the Python Package Index (PyPI).
sudo apt-get install python-pip
install python package: termcolor
termcolor is Color formatting for output in terminal
pip install termcolor
Install python package: configparser


The ConfigParser module has been renamed to configparser in Python 3. The 2to3 tool will automatically adapt imports when converting your sources to Python 3.
sudo pip install configparser
Go to your squidmagic dirctory which you had downloaded, if not you can download the tool
Now we can run the script to following command.
python /path of your access.log
                 _     _                       _
                (_)   | |                     (_)
 ___  __ _ _   _ _  __| |_ __ ___   __ _  __ _ _  ___
/ __|/ _` | | | | |/ _` | '_ ` _ \ / _` |/ _` | |/ __|
\__ \ (_| | |_| | | (_| | | | | | | (_| | (_| | | (__
|___/\__, |\__,_|_|\__,_|_| |_| |_|\__,_|\__, |_|\___|
        | |                               __/ |
        |_|                              |___/

Analyzing by SBL Advisory...
 Spam server detected, ip is
Analyzing by SBL_CSS Advisory...
 safe server detected, host or ip is
Analyzing by PBL Advisory...
 safe server detected, host or ip is
